4-12
4
4.1 Use of Navigation Tools
y
yyy
Operation if Individual is selected
A line perpendicular to the own ship and the intersection marker "----○" are displayed on an
operable line.
Turning the [EBL] dial changes the direction.
Pressing the [VRM] dial changes the range, end point 1, or end point 2 to be operated.
An operable point is displayed with "
" and can be operated by turning the [VRM] dial.
If Sequential is selected for [3] Control, the parallel index lines of the next number can be
displayed by pressing the [EBL] dial.
To close the menu, left click 0. Exit software button.
Operation if Equiangular is selected
Select a group of lines to be operated according to the setting of [3] Control.
Pressing the [EBL] dial switches between the direction change mode and elevation-angle change
mode. Turning the [EBL] dial changes the direction or elevation angle.
[3] Control
Determines whether to operate all the lines at the same time. The setting items are determined by the
setting of [2] Operation Mode
.
If All is selected
The setting cannot be changed.
All :All the lines are operated at the same time.
If Individual is selected
Determines whether to set consecutive lines or individual lines.
Sequential :Lines are operated sequentially.
Index Line1 to Line8 :A specified line is operated.
If Track or Equiangular is selected
Select a group of lines to be operated.
Group1 to Group4 :A specified group is operated.
[4] Floating
Moves the center point of parallel index lines.
Off :The starting point of parallel index lines is defined as the own ship's
position.
Screen Fix :The center of parallel index lines is moved and fixed on the radar display.
L/L Fix :The center of parallel index lines is moved and fixed at the latitude
and :longitude. (The navigator needs to be connected.)
To Next Page
