2-21
⑫ and ⑬：EBL1 / EBL2 starting point mode switching
The EBL starting point is set to CCRP or any position on the radar screen whenever this button is clicked.
⇒ C ⇒ D ⇒
: Center :The starting point is fixed to the CCRP position.
C : Screen Fix :The starting point is set to the cursor position. When left-click
subsequently, the starting position is fixed to the cursor position.
D : L/L Fix :The starting point is set to the cursor position. When left-click
subsequently, the starting position is fixed to the latitude / longitude of the cursor.
(Connection of a navigator is necessary.)
When the starting point is moved outside of the screen, the operation is reset
automatically and the starting point returns to the CCRP position.
* D is enabled only when a navigator is connected.
⑭：Parallel index line setting
The function sets the parallel index line display to On/Off and acquires the operation right.
When the button is clicked, the operation right is acquired and the menu is opened. After setting,
determine the setting by left-clicking.
⑮：Parallel index line starting point mode switching
The parallel index line starting point is set to CCRP or any position on the radar screen whenever, this
button is clicked.
In the same way as for the EBL starting point, three options are available, : Center, C : Screen Fix,
and D : L/L Fix.
