13 Configuration
Analog input x
The user can perform the allocation in this dialog window using the setup program. Further op-
tions can be seen in the following list.
• Setup program: "NV connecting list: Analog" menu
HMI > C
ONFIGURATION LEVEL > NV CONNECTING LIST: ANALOG
• Multifunction panel: "HMI analog inputs" menu
D
EVICE MANAGER > CONFIGURATION > CPU > NV CONNECTING LIST > HMI ANALOG INPUTS
Unit % Unit in which the recorded signal is to be
displayed, with a max. length of five
characters. The unit is displayed wher-
ever the measured value is displayed in
numerical form.
Comma format XXXX.X The comma format determines the num-
ber of pre-decimal and post-decimal
places for the numerical display of the
measured values. If required, the multi-
function panel automatically switches to
a different format in order to display all
pre-decimal places.
First and foremost, all pre-decimal
places must be displayed.
Alarm The user can configure up to two alarms
for monitoring two limit values.
Chapter 13.5.1 "Alarm", page 138
