13 Configuration
13.8.1 Alarm
Monitoring with an event/alarm can be activated for each digital input.
Setup dialog
Parameter
Parameter Selection/settings Description
Alarm type No alarm type is set by default.
Alarm The "Alarm" setting leads to an alarm
(incl. collective alarm) and to an entry in
the alarm list and the event list.
Event The "Event" setting leads to an entry in
the event list; the alarm signals are not
set.
Alarm text Use default text or enter other text. Text that is displayed or entered in the
alarm list and event list.
If the alarm type = Alarm, the text is also
displayed in the status and title line.
Alarm rejection Inactive
Digital selector
Signal for activating the alarm rejection
Alarm delay 0sto 65535 s Delay time for alarm triggering
Alarm active at High (1) Alarm at high level (1)
Low (0) Alarm at low level (0)
