13 Configuration
152
Parameter
Max. recording time
The maximum recording time is automatically calculated. It depends on several factors, in par-
ticular on the set memory cycle (memory rate). In case of one activated group with 6 analog
and 6 digital channels in normal operation and storing the average values, the following data
apply (entries in the event list reduce the max. recording time).
Memory cycle > max. recording time:
125 ms > 30 days; 1 s > 30 days; 5 s > 5 month; 10 s > 10 month; 60 s > 60 month
13.11.1 Analog channels
Setup dialog
Parameter Selection/settings Description
Status This parameter determines what happens with the group.
Inactive
(factory setting for group 4 to 9)
The group data is neither displayed nor
saved.
Display only The group data is displayed on the
screen.
Display / Save
(factory setting for group 1 to 3)
The group data is displayed on the
screen and saved. The group data can
only be evaluated using a PC if it has
been saved.
Name Use default text or enter other text. Description of the group, with a max.
length of 21 characters. The description
is displayed in the individual visualiza-
tions.
