JUMO mTRON T - Batch Evaluation: Report

7 Visualization
76
7.9.2 Batch evaluation: Report
Group selection
This function is used to directly select and display one of the active groups. Simply touch one
of the group designations displayed after calling up the function.
Channel rotation
This function is used to switch between the individual channels of the active group.
Group rotation
In contrast to the "Group selection" function, in which any group can be selected, this function
displays the groups one after the other.
(1)
(6) (8)
(2)
(3)
(4)
(5) (7)
(1) Specifications for maximum (2) Specifications for minimum
(3) Specifications for average (4) Specifications for batch start and batch end
(5) Group selection (6) Channel rotation
(7) Group rotation (8) End batch evaluation
NOTE!
The function is only available if more than one group is active.
(1)
(1) Group number
