13 Configuration
Memory values
In eco operation, the configured memory rate is regarded as a max. memory rate. Saving is not
performed faster under any circumstances, even if the values change more quickly. The anal-
ysis of the tolerance band is always performed using the instantaneous value and only at the
times of the configured memory rate.
If a measured value is saved in eco operation, it is simultaneously used as a new reference.
Chapter 2.6.2 "Eco operation", page 27
13.11.6 Event operation
Setup dialog
NOTE!
If the memory rate is set to 0 (= 125 ms), 8 measured values will be saved during the save
operation, rather than 1.
NOTE!
If the "Min. memory rate" is below the "Memory rate", eco operation is disabled; this means
that the instantaneous values are saved.
NOTE!
Please observe the description of the operating modes!
Chapter 2.6 "Operating modes", page 25
