9 Alarm and event lists
9.2 Selection from one of the visualizations
This function corresponds to the previous chapter.
 Chapter 9.1 "Selection from the multichannel controller module", page 91
9.3 Calling up from the memory display
If the "Alarm and event lists" function is selected from a memory display, the system displays
the events immediately. There are no alarm lists.
The list is limited to the results that are relevant for the group being displayed.
The message located nearest to the position of the cursor is highlighted in the list.
Event list (HMI)
The following figure shows "All events" from a multifunction panel.
(1)
(1) Cursor
