Measure. val. select.
The measured value selection parameter can be used to choose between min. and max. The
setting only influences the numerical display of the measured values in the "Diagram" visual-
ization, but only if min. and max. values are recorded simultaneously. When recording the min.
and max. values, the recorder works internally with the maximum sampling rate and saves both
the measured minimum and the measured maximum within the active memory rate. The mea-
sured value selection determines which value is displayed in the diagram header.
The recording of the min. and max. values is configured using the "Memory values" parameter
of the operating modes (standard, event, and time operation).
Show envel. diagram
This parameter determines whether the measured value diagrams (only with recording of min.
and max. values activated) in the Diagram display are displayed as an envelope diagram or as
a line. If the data recording is not performed in min. and max. value recording mode, the pa-
rameter continues to have no effect.
The recording of the min. and max. values is configured using the "Memory values = Min./max.
values" parameter of the operating modes (standard, event, and time operation).
13.11.5 Standard operation
Perforation If perforation is activated, holes are displayed in the diagram display on the left
and right at the edge of the screen in the manner made familiar by paper chart
recorders. However, this requires the display of the digital channels to be hidden.
No Perforation switched off
Yes Perforation switched on
Diagram type
(as of system ver-
sion 03)
The parameter determines how the analog and digital signals are displayed in the
visualisation.
Vertical Vertical representation
The header rows are shown at the
upper edge.
Horizontal Horizontal representation
The header rows are shown at the
right edge.
Parameter Selection/settings Description
NOTE!
Please observe the description of the operating modes!
Chapter 2.6 "Operating modes", page 25
