13 Configuration
Setup dialog
Parameter
Parameter Selection/settings Description
Memory status On The data is saved if this operating mode
is active.
Off The data is not saved if this operating
mode is active.
Memory values Average value The average across the configured
memory rate is calculated and saved.
Current value The current value is saved at the config-
ured memory rate.
Min. value The minimum is saved at the configured
memory rate.
Max. value The maximum is saved at the config-
ured memory rate.
Min./max. value The minimum and the maximum (peak
value and envelope diagram) are saved
at the configured memory rate.
Eco operation Using this method, a save operation is
performed if the measured value devi-
ates from the previous saved value by a
specific amount or if a digital channel
belonging to the group changes its sta-
tus.
