13 Configuration
186
13.17.2 Specific settings
Setup dialog – Counter/Int. 1 to 27
Parameter
Parameter Selection/settings Description
Function Operating mode of the counter/integrator
Inactive Counter/integrator is switched off.
Counter Counter for the pulses of a digital signal
Integrator Integration of an analog signal
Operating time Determination of the length of time that
a digital signal is active.
Save The result (status of the counter/integrator) can be saved in order to evaluate it
with the PCA3000 evaluation software.
No ( ) Event is not saved.
Yes ( ) Event is saved.
