13 Configuration
Type This setting decides when the current status of the counter/integrator is saved.
Depending on the specific setting (Yes - No), the parameters from Chapter 13.17.1
"General settings", page 184 must also be taken into consideration.
Periodically Completion and restart will be deter-
mined by the "Period" and "Synch. time"
parameters.
External Completion and restart will be deter-
mined by an external control signal. The
counter/integrator functions when the
signal is set (High).
Daily The counter/integrator is counted/inte-
grated for a day (24 hours). Completion
and restart will be determined by the
"Synch. time" parameter.
Weekly The counter/integrator is counted/inte-
grated for a week. Completion and
restart will be determined by the "Week-
day" and "Synch time" parameters.
Monthly The counter/integrator is counted/inte-
grated for a month. Completion and
restart are performed on the first day of
the month at 00:00.
Yearly The counter/integrator is counted/inte-
grated for a year. Completion and restart
are performed on the first day of the
year at 00:00.
Total The counter/integrator is counted/inte-
grated for the entire duration of the cur-
rent configuration.
Daily (Start ... End) The counter/integrator is counted/inte-
grated for a period within one day.
Restart and completion will be deter-
mined by the "Start" and "End" parame-
ters.
Ext. control signal External control signal for completion and restart of the counter/integrator (for the
"External" type). The counter/integrator functions when the signal is active.
Inactive No signal selected.
Digital selector The signal (high active) can be selected
from the list of digital signals.
Parameter Selection/settings Description
