13 Configuration
188
Additional
storage
This parameter decides whether additional storage of the current statuses is to
take place (in addition to the save operation resulting from the "Type" parameter).
The current statuses are saved but not reset. Depending on the specific setting
(Yes - No), the parameters from Chapter 13.17.1 "General settings", page 184
must also be taken into consideration.
Inactive No additional storage
Periodically Completion and restart will be deter-
mined by the "Period" and "Synch. time"
parameters.
Daily The counter/integrator is counted/inte-
grated for a day (24 hours). Completion
and restart will be determined by the
"Synch. time" parameter.
Weekly The counter/integrator is counted/inte-
grated for a week. Completion and
restart will be determined by the "Week-
day" and "Synch time" parameters.
Monthly The counter/integrator is counted/inte-
grated for a month. Completion and
restart are performed on the first day of
the month at 00:00.
Yearly The counter/integrator is counted/inte-
grated for a year. Completion and restart
are performed on the first day of the
year at 00:00.
Total The counter/integrator is counted/inte-
grated for the entire duration of the cur-
rent configuration.
Daily (Start ... End) The counter/integrator is counted/inte-
grated for a period within one day.
Restart and completion will be deter-
mined by the "Start" and "End" parame-
ters.
Specific
setting
The settings from Chapter 13.17.1 "General settings", page 184 are deactivated
for the counter/integrator in question (except reset signal). Specific settings can be
configured instead ("..." button).
No ( ) The general settings apply for the coun-
ter/integrator.
Yes ( ) The specific settings apply for the coun-
ter/integrator.
Input signal Input signal that is to be counted (digital signal) or integrated (analog signal, inte-
ger signal).
Inactive No signal selected.
Analog selector (incl. integer signals) or
digital selector
The signal can be selected from the list
of signals.
Parameter Selection/settings Description
