JUMO mTRON T - Approval;Approval Marks; Case and Ambient Conditions

267
16 Appendix
16.1.4 Case and ambient conditions
16.1.5 Approval/approval marks
Case type Metal case for mounting into a panel cut-out (indoor use); front with
decor foil
Dimensions (W × H × D) 235 mm x 195 mm x 58 mm (without connection elements)
Weight (fully equipped) Approx. 1.8 kg
Protection type Front IP67, rear IP20, acc. to DIN EN 60529
Ambient temperature range -20 to +55 °C
Storage temperature range -30 to +70 °C
Resistance to climatic conditions Relative humidity ≤ 90 % annual average without condensation (cli-
matic class 3K3 acc. to DIN EN 60721-3-3 with extended tempera-
ture and humidity range)
Site altitude Up to 2000 m above sea level
Mechanical ambient conditions
1
Vibration test acc. to DIN EN 50178
Shock test acc. to DIN EN 60068-2-27
Drop test acc. to DIN EN 60068-2-32
1
Test conditions are listed in the System Descripton B 705000.8.
Approval mark Testing agency Certificate/certifica-
tion number
Inspection basis Valid for
c UL us Underwriters Laborato-
ries
E201387 UL 61010-1 (3. Ed.),
CAN/CSA-22.2
No. 61010-1 (3. Ed.)
all types
GL – hardware
GL – software
Germanischer Lloyd 14 510-15 HH GL type approval
guidelines, VI-7-1
(Ed. 2007),
VI-7-2 (Ed. 2012)
Environmental cate-
gory C, EMC1
all types;
a power supply unit
with GL type approval
is required (e.g. type
705090)
