265
16 Appendix
16.1 Technical data
16.1.1 Interfaces
USB device interface
Connector designation Setup
Connector type Mini-B
Number 1
Application To operate the setup program
Max. current 100 mA
USB host interface
Connector designation USB1 and USB2
Connector type A
Number 2
Application For reading out data via memory stick
Max. current 100 mA
System bus In
Connector designation Bus In
Connector type RJ45
Number 1
Application For connection of a base unit or router module
Connection cable Network cable (patch cable or crossover cable), at least CAT5 (S/
FTP)
Cable length Up to 100 m
System bus Out
Connector designation Bus Out
Connector type RJ45
Number 1
Application For connection of a router module
Connection cable Network cable (patch cable or crossover cable), at least CAT5 (S/
FTP)
Cable length Up to 100 m
Ethernet
Connector designation LAN
Connector type RJ45
Number 1
Application Communication with PC (setup program, data archiving, web
server), e-mail server, and Modbus master/slave
Protocols TCP/IP, HTTP, DHCP, SMTP+POP3, Modbus/TCP
Baud rate 10 Mbit/s, 100 Mbit/s
