13 Configuration
204
13.19 Undocumented parameters
Thyristor power controller, type 70906x
Device status Individual digital signals of the
power controller: See operating
manual 70500153T90... (or fol-
lowing table)
Device status signals
Faults master Faults of the power controller in single-phase
operation or of the master in case of three-
phase economy circuit or three-phase circuit
Faults slave/
slave1
Faults of the slave in case of three-phase
economy circuit or of slave 1 in case of three-
phase circuit
Faults slave2 Faults of slave 2 in case of three-phase circuit
Faults master
slave
Faults of master slave connection and commu-
nication
Hardware input/
output
Binary values of hardware inputs and outputs
Category Signal Description
CAUTION!
Incorrect configuration of the "undocumented parameters".
The system does not react as it should.
Undocumented parameters must only be changed if the user is requested to do so by a ser-
vice technician from the manufacturer.
