13 Configuration
Analog input module 4-channel
Analog inputs AI01Alarm1 to AI04Alarm1 Alarm signal 1 of analog input 1 to 4
AI01Alarm2 to AI04Alarm2 Alarm signal 2 of analog input 1 to 4
Digital inputs DI01 Signal of digital input
Alarm CollectiveAlarm Module collective alarm
Analog input module 8-channel
Analog inputs AI01Alarm1 to AI08Alarm1 Alarm signal 1 of analog input 1 to 8
AI01Alarm2 to AI08Alarm2 Alarm signal 2 of analog input 1 to 8
Digital inputs DI01 Signal of digital input
Alarm CollectiveAlarm Module collective alarm
Digital input/output module 12-channel
Digital inputs DI01 to DI12 Signal of digital input 1 to 12
Alarm CollectiveAlarm Module collective alarm
Multifunction panel 840
System bus
digital inputs
Alarm batch 1 to
Alarm batch 9
Collective alarm of batch 1 to 9 (process val-
ues)
CollectiveAlarm Collective alarm of multifunction panel (pro-
cess values)
Fault Fault in multifunction panel (independent of
process values)
Batch 1 active to Batch 9 active Signal for active batch 1 to 9
Push button 1 to
Push button 18 (as of system ver-
sion 02: 32)
Status of push button 1 to 18 (as of system ver-
sion 02: 1 to 32) in process screen
