13 Configuration
Synch. time
The synchronization time is used for completion and restart for daily, weekly, and periodical
counters and integrators. When the synchronization time is reached, all statuses are saved and
the function with the start value 0 is restarted. With the weekly type, the "Weekday" parameter
also plays a role.
The Synchronization time will be explained in more detail below, using the example of a peri-
odical counter. The closure and restart is performed at the next point in time occurring in the
time grid – dependent on Synchronizat. time and Period.
Example:
Period = 2 hours
Synchronization time = 11:30:00
Power on = 09:11:00 1st period from 09:11 to 09:30 = 19 minutes
2nd period from 09:30 to 11:30 = 2 hours
3rd period from 11:30 to 13:30 = 2 hours
etc.
Reset signal
The current statuses are not saved when the counters and integrator statuses are reset. This
function can be used when setting up a plant (test run) or as a so-called "Clear switch", for ex-
ample.
Period 1 min, 2 min, 3 min, 4 min, 5 min,
10 min, 15 min, 30 min,
1 h, 2 h, 3 h, 4 h, 6 h, 8 h, 12 h
Pulse period of counters or integrators
for which the "Type" parameter is config-
ured as "Periodical".
Weekday Sunday, Monday, Tuesday, Wednes-
day, Thursday, Friday, Saturday
Weekday on which the counters and
integrators for which the "Type" parame-
ter is configured as "Weekly" are saved
at the synchronization time and
restarted with the start value 0.
Reset signal The reset signal is used to set the counter and integrator statuses to 0 (indepen-
dent of other parameters).
Inactive No signal selected.
Digital selector The signal (high active) can be selected
from the list of digital signals.
Parameter Selection/settings Description
NOTE!
The "General setting" can be deactivated for each counter/integrator using a specific setting.
See Chapter 13.17.2 "Specific settings", page 186.
