9 Alarm and event lists
92
Event list (HMI)
The following figure shows "All events" from a multifunction panel.
Exit function
Touch the screen here to exit the function and return to the visualization from which it was
called up.
Details
If the space for an entry within the list is insufficient, more information on the selected entry can
be shown by touching the button.
Update
The display is not cyclically updated. This function is used to update the display, i.e. the system
searches for new entries that are not yet present in the list.
Symbols
Chapter 9.5 "Symbols", page 95
Selected entry
The user can select or mark an entry by touching it.
The "Details" function can be used to show additional information. This requires there to be ad-
ditional information available for the selected entry.
(1) Exit function (2) Details
(3) Update (4) Symbols
(5) Selected entry (6) Scroll display
