153
13 Configuration
Parameter
Parameter Selection/settings Description
Input signal 6 channels can be assigned to each of the 9 groups.
Analog input x Assigned signal
Analog selector Signal that is to be allocated to the input.
Line width Determines the width of the graphic measured value display.
Thin Thin line width (1 pixel)
Thick Thick line width (2 pixels)
Tol. band active Available as from channel 2 of a group.
Yes ( ), No ( ) If "Yes", the channel is compared with
channel 1 of the group. It must be
ensured that channel 1 of the group is
active (Input signal <> Inactive).
Positive tolerance Only available for channel 1 of a group.
10 "Positive tolerance" and the current
measured value of channel 1 form the
upper limit of the tolerance band. Only a
positive value can be entered.
Negative toler-
ance
Only available for channel 1 of a group.
-10 "Negative tolerance" and the current
measured value of channel 1 form the
lower limit of the tolerance band. Only a
negative value can be entered.
Positive hystere-
sis
Only available for channel 1 of a group.
2 If there is a violation of the positive toler-
ance, the current measured value from
channel 2 to 6 must fall below the cur-
rent measured value of tolerance 1, plus
the positive tolerance and minus the
positive hysteresis, in order for the
alarm to be withdrawn again. Only a
positive value can be entered for the
"positive hysteresis".
Negative hystere-
sis
Only available for channel 1 of a group.
2 If there is a violation of the negative tol-
erance, the current measured value
from channel 2 to 6 must first increase
above the current measured value of tol-
erance 1, plus the negative tolerance
and plus the negative hysteresis, in
order for the alarm to be withdrawn
again. Only a negative value can be
entered for the "negative hysteresis".
