165
13 Configuration
Parameter
Parameter Selection/settings Description
Daily Daily specifies whether a report is to be run for a day (24 hours). The completion
and restart will be determined by the Synchronizat. time parameter.
Off, On If "On", the daily report will be run.
Periodically Periodically specifies whether a period report is to be run. The completion and
restart will be determined by the Period and Synchronizat. time parameters.
Off, On If "On", the periodical report will be run.
Period 1 min to 12 h Period is used as the report end and
restart for the periodical report.
Weekly Weekly specifies whether a report is to be run for a week. The completion and
restart will be determined by the Weekday and Synchronizat. time parameters.
Off, On If "On", the weekly report will be run.
Weekday Sunday to Saturday Weekday is used together with the Syn-
chronizat. time parameter as the report
end and restart for the weekly report.
External External specifies whether an external report is to be run and also whether the
external signal (Ext. start) is set (High).
Off, On If "On", the external report will be run.
Ext. start Inactive
Digital selector
Ext. start specifies the start signal for the
external report.
Monthly Monthly specifies whether a report is to be run for a month. The completion and
restart are performed on the first day of the month at 00:00.
Off, On If "On", the monthly report will be run.
Yearly Yearly specifies whether a report is to be run for a year. The completion and restart
are performed on the first day of the year at 00:00.
Off, On If "On", the yearly report will be run.
Total Total specifies whether a report is to be run for the total duration of the current con-
figuration of the multifunction panel.
Off, On If "On", the total report will be run.
Synchronizat.
time
Synchronizat. time is used as the report end and restart for the daily, weekly, and
periodical report.
00:00:00 Time of synchronization
Out of range This parameter decides what happens if an analog channel is outside of the valid
measuring range (scaling).
Stop The reports for this channel are stopped.
If the measured values are within the
measuring range limits, these will be
restarted.
Delete The reports are set to invalid ("-----") and
only restarted following the configured
report end.
