173
13 Configuration
Text right column The formation of the text in the right column of a batch report is specified here.
Empty The field remains empty.
Set text A set text (defined by the Factory setting
parameter) is used.
Text list One of the 128 internal batch texts of the
device is used. After reconfiguration, the
text will initially be displayed under Fac-
tory setting; the user must select the
desired text from the list in the "Current
batch" visualization. The batch texts can
be defined in the setup program.
Bin. linked text One of the 128 internal batch texts of the
device is used. The selection is per-
formed using a maximum of 6 digital sig-
nals.
Chapter 13.13.1 "Binary linking",
page 170
Batch name The batch name is displayed.
Batch number 1 to 9 The corresponding batch number is
used together with an additional text
("Set text"). The batch number is incre-
mented by the multifunction panel at the
end of a batch. It can be pre-assigned
using the multifunction panel in the
Parameterization menu.
Batch start Start (date and time) of batch reporting.
Batch end End (date and time) of batch reporting.
Batch duration Time difference between batch start and
batch end.
Barcode The text in the selected line is to be filled
by a barcode scanner.
Chapter 7.8.2 "Batch control via bar-
code scanner", page 71
Text variable 1 to ... Text that can be sent to the multifunction
panel via interface.
Modbus interface description (multi-
function panel 840)
Text variable 1 to ... (base unit) Text that can be sent to the central pro-
cessing unit via interface.
Modbus interface description (cen-
tral processing unit)
Program name If a program of the program generator
(corresponding to the batch) is running,
the program name is displayed.
Parameter Selection/settings Description
