13 Configuration
198
Setpoint value SP01RampValue to
SP04RampValue
Ramp end value of ramp function 1 to 4
(if ramp function switched on)
or
Active setpoint value (external setpoint value +
setpoint value) of setpoint function 1 to 4
(if ramp function switched off)
Analog input module 4-channel
Analog inputs AI01 to AI04 Measured value of analog input 1 to 4
Analog input module 8-channel
Analog inputs AI01 to AI08 Measured value of analog input 1 to 4
Multifunction panel 840
System bus
analog inputs
Counter/Int 1 to Counter/Int 27 Current value of counter or integrator
Counter/Int clo 1 to
Counter/Int clo 27
Value of counter or integrator in most recent
closed measuring period
Process image Current process image Number of current process image on the dis-
play of the multifunction panel
0 = process image 1, 1 = process image 2 etc.
(-1 = no active process image)
Thyristor power controller, type 70906x
Measured values
master
Individual analog signals of the
power controller: See operating
manual 70500153T90... (or fol-
lowing table)
Measured values of the power controller in sin-
gle-phase operation or of the master in case of
three-phase economy circuit or three-phase
circuit
Measured values
slave/slave1
Measured values of the slave in case of three-
phase economy circuit or of slave 1 in case of
three-phase circuit
Measured values
slave2
Measured values of slave 2 in case of three-
phase circuit
Category Signal Description
