CHAPTER 15
Connecting the MX5, MX10, MX40, and
MX80 Routers to Power
Tools and Parts Required for MX5, MX10, MX40, and MX80 Router Grounding and
Power Connections on page 87
Grounding MX5, MX10, MX40, and MX80 Routers on page 88
Connecting Power to an AC-Powered MX5, MX10, MX40, and MX80 Router on page 89
Powering On an AC-Powered MX5, MX10, MX40, and MX80 Router on page 90
Connecting Power to a DC-Powered MX5, MX10, MX40, and MX80 Router on page 91
Powering On a DC-Powered MX5, MX10, MX40, and MX80 Router on page 94
Powering Off MX5, MX10, MX40, and MX80 Routers on page 95
Tools and Parts Required for MX5, MX10, MX40, and MX80 Router Grounding and
Power Connections
To ground and provide power to the router, you need the following tools and parts:
Phillips (+) screwdrivers, numbers 1 and 2
2.5-mm flat-blade (–) screwdriver
Torque-controlled driver, with a maximum torque capacity of 6 lb-in., for tightening
screws to terminals on each power supply on a DC-powered router
CAUTION: The maximum torque rating of the terminal screws on the DC
power supply is 6 lb-in. (0.7 Nm). The terminal screws may be damaged
if excessive torque is applied. Use only a torque-controlled driver to tighten
screws on the DC power supplyterminals.Use an appropriatelysizeddriver,
with a maximum torque capacity of 6 lb-in. or less. Ensure that the driver
is undamaged and properly calibrated and that you have been trained in
its use. You may wish to use a driver that is designed to prevent overtorque
when the preset torque level is achieved.
Wire cutters
Electrostatic discharge (ESD) grounding wrist strap
87Copyright © 2017, Juniper Networks, Inc.
