Juniper MX10 - Power Consumption for a DC-Powered MX5, MX10, MX40, and MX80 Router

• MX5, MX10, MX40, and MX80 Routers AC Power Specifications on page 53
• MX5, MX10, MX40, and MX80 Routers DC Power Specifications on page 59
MX5, MX10, MX40, and MX80 Power Supply LED
Each power supply has a bi-color status LED located above the power switch on the
power supply.
Table 17: Power Supply LED
DescriptionStateColor
Power supply is functioning normally.On steadilyBlue
Power supply has failed.BlinkingRed
PEM is in offline mode.OfflineRed
Related
Documentation
• MX5, MX10, MX40, and MX80 Power System Description on page 35
• Maintaining the MX5, MX10, MX40, and MX80 Power Supplies on page 161
• Troubleshooting the MX5, MX10, MX40, and MX80 Power Supplies on page 170
• MX5, MX10, MX40, and MX80 Routers AC Power Specifications on page 53
• MX5, MX10, MX40, and MX80 Routers DC Power Specifications on page 59
