Table 26: AC Base Router Power Requirements for the Modular MX5,
MX10, MX40, and MX80 Routers
Power Requirement (Watts)
with 85% EfficiencyPower Requirement (Watts)
Modular Chassis
Configuration
365 W310 WChassis running at high
activity, with four 10-Gigabit
Ethernet XFPs, two MICs,
and fans running at high
speed
Table27 on page55 lists the power requirements for various hardware components when
the router is operating under typical voltage conditions.
Table 27: Component Power Requirements
Power Requirement
(Watts) with 85%
Efficiency
Power
Requirement
(Watts)Component
41 W35 WMIC (generalized value)
These examples use generalized values per MIC. For exact MIC power requirements, see
the MX Series Interface Module Reference.
The following calculations show the typical power consumption for modular AC-powered
routers @ 220 V (includes 85% efficiency):
•
Active AC-powered router with one MIC:
Base router (high activity, with four 10-Gigabit Ethernet XFPs, and fans running at high
speed) + 1 MIC =
282 W + 41 W = 323 W
•
Active AC-powered router with two MICs:
Base router (high activity, with four 10-Gigabit Ethernet XFPs, and fans running at high
speed) + 2 MICs
282 W + 2(41 W)= 364 W
•
Example of calculating system thermal output:
Watts AC PEM * 3.41 = BTU/hr
500 W * 3.41 = 1,705 BTU/hr
Related
Documentation
MX5, MX10, MX40, and MX80 Power System Description on page 35•
• Maintaining the MX5, MX10, MX40, and MX80 Power Supplies on page 161
• Replacing an MX5, MX10, MX40, and MX80 AC Power Supply on page 136
• AC Power Electrical Safety Guidelines and Warnings for MX5, MX10, MX40, and MX80
Routers
55Copyright © 2017, Juniper Networks, Inc.
Chapter 8: AC Power Specifications and Requirements
