CHAPTER 7
Preparation Overview
•
MX5, MX10, MX40, and MX80 Routers Physical Specifications on page 41
•
MX5, MX10, MX40, and MX80 Router Environmental Specifications on page 42
•
MX5, MX10, MX40, and MX80 Router Grounding Specifications on page 43
•
MX5, MX10, MX40, and MX80 Site Preparation Checklist on page 44
•
MX5, MX10, MX40, and MX80 Rack Requirements on page 46
•
MX5, MX10, MX40, and MX80 Routers Clearance Requirements for Airflow and
Hardware Maintenance on page 47
•
MX5, MX10, MX40, and MX80 Routers Cabinet Requirements and
Specifications on page 48
•
MX5, MX10, MX40, and MX80 Installation Summary on page 50
MX5, MX10, MX40, and MX80 Routers Physical Specifications
Table 18 on page 41 summarizes the physical specifications for the router.
Table 18: MX5, MX10, MX40, and MX80 Physical Specifications
HeightDepthWidthWeightDescription
3.5 in. (8.9 cm)23.46 in. (59.6 cm)
(including cable
management bracket
and MIC release lever)
17.5 in. (44.5 cm)Chassis with fan tray
and power supplies:
28 lb (12.7 kg)
Fixed chassis
3.5 in. (8.9 cm)23.46 in. (59.6 cm)
(including cable
management bracket
and MIC release lever)
17.5 in. (44.5 cm)Chassis with fan tray,
power supplies, and
MICs: 30 lb (13.6 kg)
Modular chassis
3.35 in. (8.5 cm)18.43 in. 46.81 cm)0.25 in. (0.64 cm)0.1 lb (0.05 kg)Air filter
1.2 in. (3.05 cm)6.8 in (17.3 cm)6.25 in. (15.9 cm)Maximum up to 1.2 lb
(0.54 kg)
MIC
1.2 in. (3.05 cm)6.8 in (17.3 cm)12.5 in. (31.75 cm)1.9 lb (0.9 kg)Dual-wide MIC
3.35 in. (8.5 cm)20.5 in. 52.07 cm)2.75 in. (6.96 cm)2.3 lb (1.04 kg)Fan tray
