Fiber-optic 10-gigabit small form-factor pluggable (XFP) transceivers:
•
Connector: Duplex LC/PC (Rx and Tx)
•
10GBASE-E (model number: XFP-10G-E-OC192-IR2)
•
10GBASE-L (model number: XFP-10G-L-OC192-SR1)
•
10GBASE-S (model number: XFP-10G-S)
•
10GBASE-Z (model number: XFP-10G-Z-OC192-LR2)
Optical interface specifications—see 10-Gigabit Ethernet 10GBASE Optical Interface
Specifications.
•
DWDM Tunable XFP transceivers:
•
Connector: Duplex LC/PC (Rx and Tx)
•
10GBASE-ZR (model number: XFP-10G-CBAND-T50-ZR)
DWDM supported wavelengths—see 10-Gigabit Ethernet DWDM Transceiver
Wavelengths
NOTE: XFP-10G-CBAND-T50-ZR is supported in Junos 11.2R2 and later
Optical interface specifications—see 10-Gigabit Ethernet 10GBASE Optical Interface
Specifications
Built-in Tri-Rate MIC
The built-in 48-port Tri-Rate MIC is available only on the fixed MX80 chassis (MX80-48T)
and is not replaceable. The built-in Tri-Rate MIC has the following components:
•
48 autonegotiating 10Base-T, 100Base-TX, or 1000Base-T Megabit Ethernet ports.
•
Autonegotiation between Gigabit Ethernet circuit partners.
•
Maximum transmission units (MTUs) of up to 9192 bytes.
•
Connector: Four-pair, Category 5 shielded twisted-pair connectivity through an RJ-45
connector.
•
Pinout: MDI/MDI-X.
•
Maximum distance: 328 ft (100 m).
•
Link LED, one green per port. For more information, see Table 16 on page 33.
Related
Documentation
MX5, MX10, MX40, and MX80 Modular Interface Card LEDs on page 33•
• Maintaining the MX5, MX10, MX40, and MX80 MICs on page 159
• Troubleshooting the MX5, MX10, MX40, and MX80 MICs on page 170
• Replacing an MX5, MX10, MX40, and MX80 MIC on page 118
25Copyright © 2017, Juniper Networks, Inc.
Chapter 5: Line Card Components and Descriptions
