3. Verify that each transceiver is covered by a rubber safety cap. If it is not, cover the
transceiver with a safety cap.
4. Carefully align the transceiver with the slots in the component. The connectors should
face the component.
5. Slide the transceiver until the connector is seated in the component slot. If you are
unable to fully insert the transceiver, make sure the connector is facing the right way.
6. Close the ejector handle of the transceiver.
7. Remove the rubber safety cap from the transceiver and the end of the cable. Insert
the cable into the transceiver.
WARNING: Do not look directly into a fiber-optic transceiver or into the
ends of fiber-optic cables. Fiber-optic transceivers and fiber-optic cable
connected to a transceiver emit laser light that can damage your eyes.
8. Verify that the status LEDs on the component faceplate indicate that the SFP or XFP
is functioning correctly. For more information about the component LEDs, see the MX
Series Interface Module Reference.
Related
Documentation
MX5, MX10, MX40, and MX80 Modular Interface Card Description on page 23•
• Replacing a Cable on an MX5, MX10, MX40, and MX80 MIC on page 126
• Removing an MX5, MX10, MX40, and MX80 Transceiver on page 130
• Preventing ElectrostaticDischarge Damage to an MX5, MX10, MX40, and MX80 Router
on page 194
Replacing an MX5, MX10, MX40, and MX80 SFP or XFP Transceiver
Small form-factor pluggable transceivers (SFPs) and 10-gigabit small form-factor
pluggables (XFPs) are optical transceivers that are installed in a MIC. SFPs and XFPs are
hot-insertable and hot-removable.
•
Removing an MX5, MX10, MX40, and MX80 Transceiver on page 130
•
Installing an MX5, MX10, MX40, and MX80 Transceiver on page 132
Removing an MX5, MX10, MX40, and MX80 Transceiver
Removing an SFP or XFP transceiver does not interrupt MIC functioning, but the removed
SFP or XFP no longer receives or transmits data.
Copyright © 2017, Juniper Networks, Inc.130
