• AC Power Circuit Breaker Requirements for the MX5, MX10, MX40, and MX80 Router
on page 56
• AC Power Cord Specifications for MX5, MX10, MX40, and MX80 Routers on page 56
AC Power Circuit Breaker Requirements for the MX5, MX10, MX40, and MX80 Router
We recommend that you use a dedicated customer site circuit breaker rated for
15 A (110 VAC) minimum or 10 A (220 VAC) minimum for each AC power feed, or as
required by local code. Doing so enables you to operate the router in any configuration
without upgrading the power infrastructure.
Related
Documentation
MX5, MX10, MX40, and MX80 Power System Description on page 35•
• Maintaining the MX5, MX10, MX40, and MX80 Power Supplies on page 161
• Replacing an MX5, MX10, MX40, and MX80 AC Power Supply on page 136
• Power Consumption for an AC-Powered MX5, MX10, MX40, and MX80 Router on
page 54
• AC Power Electrical Safety Guidelines and Warnings for MX5, MX10, MX40, and MX80
Routers
• AC Power Cord Specifications for MX5, MX10, MX40, and MX80 Routers on page 56
AC Power Cord Specifications for MX5, MX10, MX40, and MX80 Routers
Each AC power supply has a single AC appliance inlet located on the power supply that
requires a dedicated AC power feed. Most sites distribute power through a main conduit
that leads to frame-mounted power distribution panels, one of which can be located at
the top of the rack that houses the router. An AC power cord connects each power supply
to the power distribution panel.
You can order detachable AC power cords, each approximately 8 ft (2.5 m) long that
supply AC power to the router. The C13 appliance coupler at the female end of the cord
inserts into the AC appliance inlet coupler, type C14 as described by International
Electrotechnical Commission (IEC) standard 60320. The plug at the male end of the
power cord fits into the power source receptacle that is standard for your geographic
location.
Table 28 on page 56 provides specifications on the AC power cord provided for each
country or region.
Table 28: AC Power Cord Specifications
Plug TypeElectrical SpecificationModel NumberCountry
AS/NZ 3112–1993250 VAC, 10 A, 50 HzCBL-JX-PWR-AUAustralia
GB2099.1 1996 and GB1002
1996 (CH1-10P)
250 VAC, 10 A, 50 HzCBL-JX-PWR-CHChina
Copyright © 2017, Juniper Networks, Inc.56
MX5, MX10, MX40, and MX80 3D Universal Edge Router Hardware Guide
