Table 15: MX80-48T Components and Interface Names (continued)
Interface NamesName in the CLIComponent
ge-1/0/port
ge-1/1/port
ge-1/2/port
ge-1/3/port
48x1 RJ45
Each PIC is shown as 12x 1GE(LAN) RJ45
Built-in 48-port Tri-Rate MIC
Related
Documentation
MX5, MX10, MX40, and MX80 Hardware Components and CLI Terminology on page 7
MX5, MX10, MX40, and MX80 Modular Interface Card Description on page 23
MICs Supported by MX Series Routers on page 26
MX5, MX10, MX40, and MX80 Modular Interface Card LEDs
The fixed 10-Gigabit Ethernet Modular Interface Card (MIC) has link LEDs located on the
front panel. For more information about the link LEDs for the 10-Gigabit Ethernet MIC,
see “Link LEDs on the Front Panel” on page 16.
Each hot-removable and hot-insertable MIC has LEDs located on the faceplate. For more
information about LEDs on the MIC faceplate, see the “LEDs” section for each MIC in the
MX Series Interface Module Reference.
On the fixed MX80 chassis, each of the 48 ports on the fixed Tri-Rate MIC has a link LED.
Table 16 on page 33 describes the link LEDs in more detail.
Table 16: Tri-Rate MIC LEDs
DescriptionStateColor
Link is up.On steadilyGreen
No link.Off
Related
Documentation
MICs Supported by MX Series Routers on page 26
MX5, MX10, MX40, and MX80 Modular Interface Card Description on page 23
Maintaining the MX5, MX10, MX40, and MX80 MICs on page 159
Troubleshooting the MX5, MX10, MX40, and MX80 MICs on page 170
Replacing an MX5, MX10, MX40, and MX80 MIC on page 118
33Copyright © 2017, Juniper Networks, Inc.
Chapter 5: Line Card Components and Descriptions
