N9030B PXA Signal Analyzer Service Guide 201
Front End Control Troubleshooting
A15 Front End Control Description
Table 6-1 A15 Option Related Control
Option Description Physical Location in the Analyzer
P03 100 kHz to 3.6 GHz Internal Preamplifier A15 to A13
P08 100 kHz to 8.4 GHz Internal Preamplifier A15 to A11 and A13
P13 100 kHz to 13.6 GHz Internal Preamplifier A15 to A11 and A13
P26 100 kHz to 26.5 GHz Internal Preamplifier A15 to A11 and A13
P43 100 kHz to 43 GHz Internal Preamplifier A15 to A11 and A13
P44 100 kHz to 44 GHz Internal Preamplifier A15 to A11 and A13
P50 100 kHz to 50 GHz Internal Preamplifier A15 to A11 and A13
ALV Log Video Out A15 to Aux IF Output (rear panel)
CRP Arbitrary I.F. Out A15 to Aux IF Output (rear panel)
CR3 2nd I.F. Out A15 to Aux IF Output (rear panel)
LNP Low Noise Path A15 to SW3
MPB Microwave Preselector Bypass A15 to SW1 and SW2 (Opt 508, 513, or 526)
A15 to SW4 (Opt 544, or 550)
EA3 Electronic Attenuator A15 to A13
