260 N9030B PXA Signal Analyzer Service Guide
LO Synthesizer/Reference Troubleshooting
A14 LO Synthesizer and A20 YTO Troubleshooting
6. Press Peak Search on the functioning spectrum analyzer. The analyzer
marker should read 100 MHz at +13 dBm ±3 dB as shown in Figure 8-6.
Figure 8-6 100 MHz Wide Span
