390 N9030B PXA Signal Analyzer Service Guide
Replaceable Parts
Replaceable Parts
W60 Cable, semi-rigid, Switch 4 Port 4 to YTF Input
(Options 544, 550 with Option LNP or MPB)
N9020-20128
W61 Cable, semi-rigid, YTF Output to Switch 4 Port 3
(Options 544, 550 with Option LNP or MPB)
N9020-20129
W62 Cable, semi-rigid, Switch 4 Port 2 to A13A1 Input J9
(Options 544, 550 with Option LNP or MPB)
N9020-20130
W63 Cable, ribbon A26 WBDIF J9000 to A28 WBDIF Extension board J1
(Option RTS)
N9020-60278
W64 Cable, ribbon A27 WBDIF J9000 to A28 WBDIF Extension board J2
(Options RTS and B5X)
N9020-60278
W65 Cable, Flex Circuit A25 WB AIF to A26 WB DIF (Option B2X) N9030-60033
W66 Cable, Flex Circuit A25 WB AIF to A26 WB DIF and A27 WB DIF
(Option B5X)
N9030-60034
W67 Spare
W68 Cable, Coax, A16J726 Reference Assembly to A25J1, WB A-IF
Assembly (Option B2X or B5X)
8121-0152
W69 Cable, Coax, A16J718 Reference Assembly to A25J4, WB A-IF
Assembly (Option B2X or B5X)
8121-0152
W70 Cable, Coax, A25J17, WB A-IF Assembly to A15J901, Front End
Controller (Option B2X or B5X)
8121-1865
W71 Cable, Coax, A25J18 WB A-IF Assembly to A3J15, Digital IF Assembly
(Option B2X or B5X)
8121-1401
W72 Cable, Coax, A25J2 WB A-IF Assembly to A3J17, Digital IF Assembly
(Option B2X or B5X)
8121-1401
W73 Cable, Semi-rigid, A14J1 Synthesizer Assembly to A13J4, Front End
Assembly (Option EP0)
N9020-20301
W74 Cable, Semi-rigid, Front End A13J9 to lower coax switch port C
(Option B2X, B5X)
N9020-20305
W75 Cable, Semi-rigid, Front End A13J8 to W29
(Option EXM, 508, 513, 526)
N9020-20304
Cable, Semi-rigid, Front End A13J8 to W29
(Option EXM, 544, 550)
N9020-20167
W76 Cable, Semi-rigid, A13 IF Out to SW5 port C
(Option B5X, 508, 513, 526, 544, 550)
N9020-20266
W77 Cable, Semi-rigid, SW5 port 1 to BP Filter In (Option B5X) N9020-20268
Table 15-1 All Replaceable Parts
Reference
Designator
Description Part Number
