N9030B PXA Signal Analyzer Service Guide 391
Replaceable Parts
Replaceable Parts
W78 Cable, Semi-rigid, SW5 port 2 to Switched Filter In (Option B5X) N9020-20267
W79 Cable, Semi-rigid, Switched Filter Out to SW6 port 2 (Option B5X) N9020-20292
W80 Cable, Semi-rigid, BP Filter Out to SW6 port 1 (Option B5X) N9020-20293
W81 Cable, Semi-rigid, A14 Synthesizer Assembly to FL2, 7.2 GHz BPF
(Option EP0)
N9020-20226
W82 Cable, Semi-rigid, A16J703 Reference Assembly to FL2, 7.2 GHz BPF
(Option EP0)
N9020-20303
W83 Cable, Semi-rigid, A14J2 Synthesizer Assembly to A20 YTO Assembly
output (Options 503, 508, 513, 526 with Option EP0)
N9020-20302
Cable, Semi-rigid, A14J2 Synthesizer Assembly to A20 YTO Assembly
output (Options 544, 550 with Option EP0)
N9020-20298
W84 Cable, Semi-rigid, SW6 port C to A13 IF IN J11
(Options B5X, 508, 513, 526)
N9020-20265
Cable, Semi-rigid, SW6 port C to A13 IF IN J11 (Options B5X, 544, 550) N9020-20276
a. Included, but not required for use on N9030B.
b. Does not include nameplate. See A1MP3 through A1MP8.
c. The E4410-60121 is the preferred replacement for the N9020-60255, Low Band Switch that may
be installed in some N9030Bs with Option 503.
d. Does not include A1A1MP20 or A1A1MP21 overlays.
Table 15-1 All Replaceable Parts
Reference
Designator
Description Part Number
