Keysight Technologies N9030B User Manual

Chapter 15 393
Replaceable Parts
Replaceable Parts
Display Bracket Front Frame 2 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Disk Drive Disk Drive Tray 4 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Disk Drive Handle Disk Drive Rear Panel 2 0515-1227 M3 X 0.5
(6 mm long)
Torx T-10 9 inch-lbs
Disk Drive Interconnect CPU Assembly 2 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Disk Drive Rear Panel Disk Drive Tray 4 0515-2219 M2.5 X 0.45
(5 mm long)
Torx T-8 6 inch-lbs
External Reference BNC Rear Panel 1 2190-0102 Lock Washer n/a n/a
1 0590-2332 Hex Nut 9/16” Nut
Driver
21 inch-lbs
Fan Fan Bracket 4 per 0361-1272 Rivets n/a n/a
Fan Assembly Chassis 7 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Front Frame Assembly Chassis 8 0515-2032 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Front Panel Connector Cover
Plate
Front Frame 2 0515-1227 M3 X 0.5
(6 mm long)
Torx T-10 9 inch-lbs
Front Panel Daughter Board Front Frame 3 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Front Panel Interface Board Front Frame 13 0515-1521 M3 X 0.5
(5 mm long)
Torx T-10 9 inch lbs.
Table 15-2 Attaching Hard ware
Attach To Qty Part Number Type Tool Torque
