394 Chapter 15 Replaceable Parts Replaceable Parts
Front Panel Shield Front Frame 4 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
LO Synthesizer Assembly Chassis 2 0515-2032 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Low Band Switch Assy. Low Band Switch Bracket 4 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Low Band Switch Bracket. Chassis 2 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Midplane Assembly Midplane Bracket 6 0515-0375 M3 X 0.5
(16 mm long)
Torx T-10 9 inch-lbs
Midplane Bracket Chassis Sides 4 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Motherboard 4 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Motherboard Chassis Bottom 4 0515-0372 M3 X0.5
(8 mm long)
Torx T-10 9 inch-lbs
Power Supply Bracket Chassis 8 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Power Supply 3 0515-1946 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Preselector Bypass Switch
(Option 508, 513, 526)
Preselector Bypass Switch
Bracket
2 per 0515-1992 M2.5 X 0.45
(20 mm long)
Torx T-8 6 inch-lbs
Preselector Bypass Switch
(Option 544, 550)
Preselector Bypass Switch
Bracket
3 0515-1934 M2.5 X 0.45
(6 mm long)
Torx T-8 6 inch-lbs
Preselector Bypass Switch
Bracket
Low Band Switch Bracket 1 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Table 15-2 Attaching Hard ware
