N9030B PXA Signal Analyzer Service Guide 553
Post-Repair Procedures
Post-Repair Procedures
Table 17-1 Post-Repair Testing Requirements
Assembly
Adjustments to Perform
(in the order listed)
a
Performance Verifications to Perform After
Adjustments
a
A1A2
Front Panel
Interface
None Residual Responses
Displayed Average Noise Level
A1A3
Liquid Crystal
Display
None Residual Responses
Displayed Average Noise Level
A2
Analog IF Assembly
IF Flatness Adjust (Option B25, B40, or B1X if
Option MPB is also present)
Power Bandwidth Accuracy
Resolution Bandwidth Switching Uncertainty
Residual Responses
Displayed Average Noise Level
IF Frequency Response (Option B25, B40, B1X)
Absolute Amplitude Accuracy
Display Scale Fidelity
A3
Digital IF Assembly
FPGA Synchronization
b
Power Bandwidth Accuracy
Resolution Bandwidth Switching Uncertainty
Residual Responses
Displayed Average Noise Level
IF Frequency Response (Option B25, B40, B1X)
Absolute Amplitude Accuracy
Display Scale Fidelity
A4
CPU Assembly
BIOS Settings Verification
b
Set Instrument Time and Date
c
Residual Responses
Displayed Average Noise Level
A4BT1
Battery
BIOS Settings Verification
b
Set Instrument Time and Date
c
Residual Responses
Displayed Average Noise Level
A5
Disk Drive
d
Accept End User License Agreement (EULA)
b
Instrument Software Update
e
All Adjustments
d
f
Residual Responses
Displayed Average Noise Level
Frequency Response (All Tests)
A6
Power Supply
None Residual Responses
Displayed Average Noise Level
Spurious Responses
A7
Midplane board
Program Instrument Model and Serial
Number
b
Residual Responses
Displayed Average Noise Level
A8
Motherboard
None Run all tests since instrument was disassembled.
