576 N9030B PXA Signal Analyzer Service Guide
Functional Tests
Test Equipment
Cables
All 3.5 mm (1 meter) Frequency: 10 MHz to 26.5 GHz
VSWR: < 1.4:1
Loss: < 2.0 dB
11500E 8120-4921
544, 550 2.4 mm (1 meter) Frequency: 10 MHz to 50 GHz
VSWR: < 1.55:1 at 50 GHz
Loss: < 6.0 dB at 50 GHz
8120-6164
All Cable, BNC
(3 required)
120 cm (48 in.) BNC cable 10503A
BBA Cable, BNC 120 cm (48 in.) BNC cable
Flatness:(250 kHz to 40 MHz) < 0.5 dB
10503A
BBA Cable, BNC BNC (m)
23 cm (9 in) max
10502A
Signal Source
All Synthesized Sweeper
Frequency: 10 MHz to 50 GHz
a
Harmonic level: < - 40 dBc
Amplitude range: 10 to - 20 dBm
Frequency Accuracy: 0.02%
PSG
b
83630B,
83640B,
83650B
BBA RF Signal Generator Frequency: 250 kHz to 40 MHz
Amplitude: ~ - 10 dBm
Flatness:< ± 0.75 dB
E4438C 33250A
Power Meter
All Power Meter Power Reference Accuracy: ±1.2%
Compatible with power sensor
E4418B E4419B
All Power Sensor Frequency Range: 50 MHz to 3.66 GHz
Amplitude Range: -70 to –20 dBm
8481D 8487D
8485D
503, 508,
513
Power Sensor Frequency Range: 50 MHz to 13.66 GHz
Amplitude Range: -30 to +20 dBm
8481A
526 Power Sensor Frequency Range: 50 MHz to 26.5 GHz
Amplitude Range: -30 to +20 dBm
8485A
544, 550 Power Sensor Frequency Range: 50 MHz to 50 GHz
Amplitude Range: -30 to +20 dBm
8487A
P03 Low Power Sensor Frequency Range: 50 MHz to 3.6 GHz
Amplitude Range: –70 to –20 dBm
8481D 8485D
8487D
Table 18-1
Analyzer
Option
Item Critical Specifications
Recommended
Keysight Model
Alternate
Keysight
Model
