8400 StateLine C | Reference manual
Diagnostics & error management
Error messages of the operating system
420 L Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011
PS02: Par. set invalid [xx.0144.00002]
PS03: Par. set device invalid [xx.0144.00003]
PS04: Par. set Mci invalid [xx.0144.00004]
PS07: Par. memory module invalid [xx.0144.00007]
PS08: Par. device invalid [xx.0144.00008]
Response (Lenze setting printed in bold)
0: No Reaction : 1: Fault 2: Trouble 3: TroubleQuickStop 4: WarningLocked 5: Warning 6: Information
Cause Remedy
The parameter set saved to the memory module is
invalid because it has not been saved completely.
• This can be due to voltage failure or caused by
removing the memory module while saving the
parameter set.
Ensure voltage supply during the storage process and
that the module remains plugged into the slot.
Response (Lenze setting printed in bold)
0: No Reaction : 1: Fault 2: Trouble 3: TroubleQuickStop 4: WarningLocked 5: Warning 6: Information
Cause Remedy
The parameter set saved to the memory module is
incompatible to the standard device.
• An incompatibility of the parameter set is caused e.g.
when the memory module of an 8400 HighLine is
plugged into an 8400 StateLine or the parameter set
in the memory module has a higher version than
expected by the standard device.
When the memory modules are exchanged, observe the
downward compatibility:
• OK: StateLine V2.0 to StateLine V3.0
• OK: StateLine V2.0 to HighLine V2.0
• Not OK: HighLine Vx.x to StateLine Vx.x
• Not OK: StateLine V3.0 to StateLine < V3.0
Response (Lenze setting printed in bold)
0: No Reaction : 1: Fault 2: Trouble 3: TroubleQuickStop 4: WarningLocked 5: Warning 6: Information
Cause Remedy
The parameter set saved to the communication module
is incompatible to the standard device.
• An incompatibility of the parameter set is caused e.g.
when the MCI module parameters in the memory
module do not match the plugged communication
module.
When the memory modules are exchanged, observe the
downward compatibility:
• OK: StateLine V2.0 to StateLine V3.0
• OK: StateLine V2.0 to HighLine V2.0
• Not OK: HighLine Vx.x to StateLine Vx.x
• Not OK: StateLine V3.0 to StateLine < V3.0
Response (Lenze setting printed in bold)
0: No Reaction : 1: Fault 2: Trouble 3: TroubleQuickStop 4: WarningLocked 5: Warning 6: Information
Cause Remedy
The parameter set saved to the memory module is
invalid.
• The error occurs while loading the parameter set.
• The memory module plugged in the device lacks a
code or a code is incorrect.
Consultation with Lenze required.
Response (Lenze setting printed in bold)
0: No Reaction : 1: Fault 2: Trouble 3: TroubleQuickStop 4: WarningLocked 5: Warning 6: Information
Cause Remedy
The parameter set in the device is invalid.
• The error occurs while loading the parameter set.
• One code in the device is incorrect.
Consultation with Lenze required.
