Lexmark MS410 series Service Manual

7 Insert the imaging unit by aligning the arrows on the side rails of the unit with the arrows on the side rails inside
the printer, and then insert the imaging unit into the printer.
8 Insert the toner cartridge by aligning the side rails of the cartridge with the arrows on the side rails inside the printer,
and then insert the cartridge into the printer.
9 Close the front door.
10 From the printer control panel, press to clear the message and continue printing.
200 paper jam messages
Error code Description Action
200.01 Input sensor covered during warm-up sequence. Go to “Sensor (input) static jam service check” on
page 53.
200.02 Input sensor covered too quickly. Go to “Sensor (input) early/late arriving service
check” on page 53.
200.03 Media did not reach input sensor from MPF.
200.05 Input sensor covered too long.
200.07 Input sensor failed to become uncovered from sheet
ahead.
200.08 Page arrive at input senor at unexpected time.
4514-420, -430
Diagnostic information
51

Lexmark MS410 series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 40 ppm
Duplex Printing	Standard
Processor Speed	800 MHz
Warranty	1-year limited warranty
Print Resolution	1200 x 1200 dpi
Connectivity	USB, Ethernet
Input Capacity	250-Sheet Input
Output Capacity	150 sheets
Mobile Printing	Lexmark Mobile Print
Operating System Compatibility	Windows, macOS, Linux
Dimensions	15.7 x 15.0 x 10.3 inches
Weight	31.0 lbs
Recommended Monthly Page Volume	750 - 3, 500 pages
