Gocator Device Files • 358
Element Type Description
Parameters\RelativeThreshold GdkParamFloat Relative threshold value.
Parameters\RelativeThreshold.
units
String Units of relative threshold (e.g.: %)
Parameters\EdgeSmoothing
GdkParamFloat
Edge smoothing value.
Parameters\EdgeSmoothing.u
nits
String Units of edge smoothing (e.g.: mm).
Parameters\EdgeWidth
GdkParamFloat
The step width.
Parameters\EdgeWidth.units String Units of edge (e.g.:mm).
Parameters\EdgeMaxGap
GdkParamFloat
Edge max gap value.
Parameters\EdgeMaxGap.units String Units of edge max gap (eg: mm).
Parameters\FillBackground
GdkParamBool
Fill background boolean
Parameters\FillValue
GdkParamFloat
Fill value value.
Parameters\FillValue.units String Units of fill value (e.g.: mm).
Parameters\IntensityFillValue
GdkParamFloat
Intensity fill value value.
Parameters\IntensityFillValue.
min
8u Intensity fill value minimum value.
Parameters\IntensityFillValue.
max
8u Intensity fill value maximum value.
Parameters\RenderDetail
GdkParamBool
Render detail Boolean.
Measurements\Measurement
@type=X
EdgeMeasurement
Base X measurement.
Measurements\Measurement
@type=Y
Edge Measurement Base Y measurement.
Measurements\Measurement
@type=Z
Edge Measurement Base Z measurement.
Measurements\Measurement
@type=ZAngle
Edge Measurement Base ZAngle measurement.
Measurements\Measurement
@type=Height
Edge Measurement Base Height measurement.
Features\Feature
@type=EdgeLine
Gdk Feature
EdgeLine line feature.
Features\Feature
@type=CenterPoint
Gdk Feature CenterPoint point feature.
@id 32s
Measurement ID. Optional (measurement disabled if not
set).
@type String Type name of measurement.
Name String Measurement name.
Enabled Boolean
Measurement enable state:
Edge Measurement Child Elements
