Chapter 3 Software overview
Page 3-12 MAN 0474
Record and reports view selector
The record parameters shown in the Record View, and the reports listed in the
Reports view are controlled using the Record and reports view selector to the
right of the of the Workspace pane. Additionally the Records and report selector
stores (and restores) any selected data quality addins.
You can add as many different views as required – these are stored within either of
the currently selected workspaces.
To add a new view:
1. Click Add new view from the Workspace pane.
2. Enter a View name in the Result View Properties window.
3. Click Configure record view columns to show the parameter selection win-
dow. Select the required parameters and then click OK.
Similarly click Configure report selection to display the Report Selection
window, select the required reports and tab order, and then click OK.
Refer to the Reporting chapter for details on report selection.
4. Once you have added new views, make them the active view by clicking on
them from the list. The selected view will now be shown as the record and
reports view selector title.
