Malvern Mastersizer 3000 User Manual

Chapter 4 Making measurements
Page 4-22 MAN 0474
SOP Player
With SOPs created and saved, users are now able to define an SOP playlist
sequence where results can be automatically collected for a single sample using dif-
ferent measurement and/or analysis settings - this is done using the SOP player.
In order to set up an SOP playlist, users first need to create a set of SOPs for the
dispersion unit they want to use that contain the measurement settings required for
the sequence. They then select the SOP Player option from the Home ribbon
bar, the SOP Player dialogue will open.
The SOP Player is only available with the Mastersizer 3000 / Mastersizer
3000E with Extended software option.

Malvern Mastersizer 3000 Specifications

General

Measurement principle	Laser diffraction
Blue laser wavelength	470 nm
Sample dispersion options	Wet and dry dispersion
Data acquisition rate	10 kHz
Particle size range	0.01 to 3500 microns
Laser type	He-Ne and solid state
Accuracy	Better than 1%
Repeatability	Better than 0.5%
Technology	Mie and Fraunhofer theories
Sample dispersion units	Hydro MV, Hydro LV, Aero S
Optical model	Mie theory
Power requirements	100-240 V, 50/60 Hz
Detector arrangement	Log-spaced array
