Malvern Mastersizer 3000 User Manual

Chapter 4 Making measurements
Page 4-4 MAN 0474
The quality and value of an SOP depends on the quality of the method develop-
ment work on which it is based. A series of manual measurements is required to
establish the ideal parameters for use in an SOP. A number of standard SOP tem-
plates have been prepared in advance for typical measurements, which may be used
unchanged or as the basis for a new SOP.
The Mastersizer application software's powerful SOP editing facility enables users
to review and refine SOPs as part of their ongoing quality control process.
Creating or editing an SOP
SOPs need to be created and saved before they can be used. To create a new SOP:
1. Select New-SOP from the Home ribbon. (To edit an existing SOP, choose
Open-SOP instead.)
2. Select an SOP template from the list in the New SOP window or click the
From an existing SOP... button to locate an SOP in the file system that fulfils
(or is close to) your required criteria.

Malvern Mastersizer 3000 Specifications

General

Measurement principle	Laser diffraction
Blue laser wavelength	470 nm
Sample dispersion options	Wet and dry dispersion
Data acquisition rate	10 kHz
Particle size range	0.01 to 3500 microns
Laser type	He-Ne and solid state
Accuracy	Better than 1%
Repeatability	Better than 0.5%
Technology	Mie and Fraunhofer theories
Sample dispersion units	Hydro MV, Hydro LV, Aero S
Optical model	Mie theory
Power requirements	100-240 V, 50/60 Hz
Detector arrangement	Log-spaced array
