Malvern Mastersizer 3000 User Manual

Chapter 7 Reporting
Page 7-14 MAN 0474
9. With all report elements positioned, alter the font style and color as required -
refer to Changing the font style for report parameters below.
10. When you have finished editing the report, click the Finish Editing button at
the top of the window.
11. The software asks whether you would like to save (changes to) the report -
click Save, Don't Save or Cancel as required.
Tip
To display a thumbnail preview of the complete report move the mouse
pointer over the icon.
Changing the font style for report parameters
It is possible to change the font style and color used for parameters included in
report parameter grids and highlight them to give key parameters more emphasis in
the final report. To do this, place the report into edit mode and hover the mouse
pointer over the parameter to be configured. This will cause a font edit icon to
appear as part of the parameter selection area.
Clicking on this icon will open a menu where the color and font style for the
parameter can be changed.

Malvern Mastersizer 3000 Specifications

General

Measurement principle	Laser diffraction
Blue laser wavelength	470 nm
Sample dispersion options	Wet and dry dispersion
Data acquisition rate	10 kHz
Particle size range	0.01 to 3500 microns
Laser type	He-Ne and solid state
Accuracy	Better than 1%
Repeatability	Better than 0.5%
Technology	Mie and Fraunhofer theories
Sample dispersion units	Hydro MV, Hydro LV, Aero S
Optical model	Mie theory
Power requirements	100-240 V, 50/60 Hz
Detector arrangement	Log-spaced array
