Malvern Mastersizer 3000 User Manual

Reporting Chapter 7
Mastersizer 3000 Page 7-13
 Add annotation - use this option to input basic text and comments about the
report, measurement or other associated information. Once the annotation
area is added to the report template, select the edit
icon and add comments
as required.
5. Choose one of these options and then select a more specific kind of report ele-
ment from the window that follows.
The new section is now added to the report in the main report editing window.
In this example, a parameter grid has been added:
6. To undo the last change made to the report, click the Undo button . If
required, continue to click Undo until all edits in that session have been
undone. To re-do a change that has been undone, click the Redo button
.
7. Click anywhere in the report section's
heading area to activate the cursor, then
edit the heading for the report section as
required.
8. To move items up or down in the report,
click the arrow buttons on the right of the
item.
Tip
To move items around a large report it is often easier to zoom out initially
(so that more of the report is visible) and then drag the report section to
the required area of the page. The mouse pointer must not be positioned
over any of the buttons when clicking and dragging.

Malvern Mastersizer 3000 Specifications

General

Measurement principle	Laser diffraction
Blue laser wavelength	470 nm
Sample dispersion options	Wet and dry dispersion
Data acquisition rate	10 kHz
Particle size range	0.01 to 3500 microns
Laser type	He-Ne and solid state
Accuracy	Better than 1%
Repeatability	Better than 0.5%
Technology	Mie and Fraunhofer theories
Sample dispersion units	Hydro MV, Hydro LV, Aero S
Optical model	Mie theory
Power requirements	100-240 V, 50/60 Hz
Detector arrangement	Log-spaced array
