Malvern Mastersizer 3000 User Manual

Making measurements Chapter 4
Mastersizer 3000 Page 4-31
If the newly added dispersant will be used in the future, add it to the Dispersants
Database by clicking Add to database.
level sensor
threshold 
(Hydro MV only)
A value can be inputted that is suitable for the level sensor to
detect the dispersant level when filled. The value will be dif-
ferent depending upon the dispersant used.
The level sensor in the dispersion unit automatically stops
the tank being overfilled above a certain level. If the tank fails
to fill properly then the level sensor threshold, for the disper-
sant being used, may need adjusting. This value can be
changed either manually (for the current measurement only)
or by using the dispersants database, to store the new val-
ues for future use.
Configuring this threshold value will be done using the
accessory controls window; this is described in the Hydro
series wet dispersion units guide.
References and
notes
Enter any further comments that help to describe the disper-
sant.
Section/option Description

Malvern Mastersizer 3000 Specifications

General

Measurement principle	Laser diffraction
Blue laser wavelength	470 nm
Sample dispersion options	Wet and dry dispersion
Data acquisition rate	10 kHz
Particle size range	0.01 to 3500 microns
Laser type	He-Ne and solid state
Accuracy	Better than 1%
Repeatability	Better than 0.5%
Technology	Mie and Fraunhofer theories
Sample dispersion units	Hydro MV, Hydro LV, Aero S
Optical model	Mie theory
Power requirements	100-240 V, 50/60 Hz
Detector arrangement	Log-spaced array
