Starting/turning off the engine for driving
4.1 Starting the engine from the driver's cab
4 - 10 3 112 993 en Operating manual GMK 6400
12.07.2013
DEF
When additional equipment is in use, the sub-
menu
Inspection shows the fill level of the DEF
tank (1).
The display (2) indicates the current level as a
percentage. 100% corresponds to about 40 l
(0.9 gal).
The level indicator below the display changes
colour depending on the level:
• Refill the DEF tank (1) in good time and close
it using the cap.
When the DEF tank is used up, the engine control system will reduce the
motor torque. You can override this torque reduction;
à Overriding torque
reduction
, p. 5 - 52.
H
In order to comply with exhaust emission regulations, the truck crane may
only be driven with DEF. Driving with an empty DEF tank will invalidate the
truck crane's licence for use on public roads.
Green: Over 10% – over 4 l (0.9 gal)
Yellow: 5 to 10% – 2 to 4 l (0.4 to 0.9 gal)
Red: Below 5% – less than 2 l (0.4 gal)
G
Risk of injury from ammonia vapours
Ammonia vapours can escape if the DEF tank is opened at high outside
temperatures. Ammonia vapours can irritate mucous membranes, skin and
eyes.
Ensure that there is adequate fresh air supply and do not breathe in the
escaping ammonia vapours.
S
Risk of damage to painted or aluminium surfaces.
DEF can corrode these surfaces. Clean up spilled DEF with water immedi-
ately.
