Driving modes and rigging for on-road driving
6.3 Removing/installing main boom
6 - 32 3 112 993 en Operating manual GMK 6400
12.07.2013
6.3.10 Transporting the main boom
Transport the main boom only on a separate vehicle which is of sufficient
size and has sufficient lifting capacity.
Transport dimensions and weight;
à Operating instructions.
• Always place the main boom onto a suitable packing.
• Secure the main boom against slipping using the holding ropes.
• Load the main boom in such a way that other road users are not put at
risk.
• Load the transport vehicle in such a way that the weight is evenly distrib-
uted.
• Secure the connection lines so that they will not slip and be damaged dur-
ing transport.
• Keep the connecting points free of contamination.
S
Risk of damage to the main boom
Always place the main boom onto a suitable packing. If you lay the main
boom on its side, add-on parts will be damaged.
